Electric Chain Hoist
Electric chain hoist is a mechanical device used for lifting and moving heavy loads with the assistance of a motor. It typically consists of a chain, a hook, and an electric motor that powers the hoisting mechanism. Chian hoist is a mechanical device used to lift and lower heavy loads using a chain. It operates through a system of gears and a chain, providing mechanical advantage and making it easier to lift heavy objects. Chain hoists can be powered manually or electrically, and they are widely used in various industrial, commercial, and construction applications.
- 1. These hoists are domestic mature product, simple structure, strong stability, high safety factor, long mechanical life, easy maintenance, and high cost performance.
- 2. Compared with the wire rope hoist, the electric chain hoist is smaller in size and lighter in weight, but the speed is slightly lower. If the lifting height is pretty high, the wire rope hoist is recommended.
Product Description
Electric chain hoist is a mechanical device used for lifting and moving heavy loads with the assistance of a motor. It typically consists of a chain, a hook, and an electric motor that powers the hoisting mechanism. Chian hoist is a mechanical device used to lift and lower heavy loads using a chain. It operates through a system of gears and a chain, providing mechanical advantage and making it easier to lift heavy objects. Chain hoists can be powered manually or electrically, and they are widely used in various industrial, commercial, and construction applications.
Technical Parameter
| Type | Lifting Capacity( Ton) | Lifting Speed(m/min) | Lifting Motor | Chain Specifications | Weight(kg) | ||
| Power(kw) | Phase | Phase | 6.3 | 32/46 | |||
| HHBB 0.5-01 | 0.5 | 7.2 | 1.1 | 3 | 380 | 71 | 59/64 |
| HHBB 01-01 | 1 | 6.8 | 1.5 | 3 | 380 | 6.3 | 49/53 |
| HHBB 01-02 | 1 | 3.6 | 1.1 | 3 | 380 | 10 | 109/121 |
| HHBB 02-01 | 2 | 6.6 | 3 | 3 | 380 | 7.1 | 68/73 |
| HHBB 02-02 | 2 | 3.4 | 1 .5 | 3 | 380 | 11.2 | 113//125 |
| HHBB 03-01 | 3 | 5.6 | 3 | 3 | 380 | 10 | 127/139 |
| HHBB 03-02 | 3 | 4.4 | 3 | 3 | 380 | 11.2 | 138/150 |
| HHBB 03-02 | 5 | 2.8 | 3 | 3 | 380 | 11 2 | 192/208 |
| HHBB 7.5-03 | 7.5 | 1.8 | 3 | 3 | 380 | 71 | 49/53 |
Advantages
- Thickened casting shell: Thickened integral casting shell, impact-resistant, safe, and sturdy.
- Safety explosion-proof motor: Motor protection grade IP66/IP65, all motors have overheating protection, equipped with Class Finsulation and Class B temperature rise.
- Explosion-proof handle operation: Ergonomic design, explosion-proof level handle operation, safe and reliable.
- Compact and exquisite structure: Small size, light weight, low noise, aesthetically pleasing appearance, strong universality,the overall structure is convenient for disassembly and assembly, easy for maintenance.
- Customized: Provides customized cost-effective solutions.
Application
- Manufacturing: For moving heavy parts and machinery.
- Construction: For lifting building materials.
- Warehousing: For handling inventory and heavy goods.
- Theater and Entertainment: For moving stage equipment and props.
