Electric Winch

Reasonable structure and design hoist.
Easy to install and Maintenance.
High efficiency and stable performance.
Top quality with competitive and economic price.
Double Speed: Low Speed and Normal Speed.
With big drum rope capacity to make you a wide range of choice for the lifting height or pulling length.

Product Description

Electric winches are mainly used for the installation of various large and medium-sized concrete, steel structures and mechanical equipment, and can also be used as a component of machinery such as lifting, road construction, and mine lifting. Mainly used for civil construction, mining area hoisting, small equipment installation, material upgrading and transformation, and plant construction.

Technical Parameter

Basic Date Type	Rated Pull(KN）	Speed(m/min)	Rope Capacity(m)	Rope Diameter(mm)	Motor Power(kw)	Overall Size(mm)	Weight(kg)
JM1	10	15	100	9.3	3	650700417	270
JM2	20	16	150	13	7.5	94596570	550
JM3.2	30	9.5	150	15.5	7.5	10801015610	1100
JM5	50	10	270	21.5	11	12351230805	1560
JM6	60	9.5	270	24	15	12351500805	1800
JM8	80	8	250	26	15	20901475956	2900
JM10	100	8	250	30	22	20901475956	3000
JM16	160	10	500	37	37	375024001850	8800
JM32	320	9	700	56	75	450028502100	14800

Advantages

Use tapered rotor of three-phase asynchronous braking motors
Stable starting,safe braking, can be used with reducer
B grade or F grade of insulation,closed structure,motor protection grade is lP44 orIP54.
Brand: Nanjing special motor

Application

Construction: Used for lifting and positioning heavy building materials and equipment.
Mining: Assists in moving heavy machinery and materials within mining operations.
Shipyards: Utilized for shipbuilding and repair tasks, such as moving large components and sections of ships.
Factories: Employed in various manufacturing processes where heavy loads need to be moved or lifted.
Infrastructure Projects: Supports tasks such as bridge construction, tunnel boring, and other large-scale infrastructure projects.
