KBK Flexible Combined Overhead Crane

KBK crane, full name KBK flexible crane, is a new type of lifting equipment with high flexibility. It is mainly composed of rail, suspension device, driving device, spreader and other parts.KBK crane adopts suspension design, can move freely in three-dimensional space, to realize all-around item handling.

Rated load: 125-2,000 kg
Light weight and high bending strength
The friction resistance of aluminum alloy track is small
Long suspension distance and long span stroke
Easy to install, modify and expand
The working area under the crane is maximized
Long life and reduced maintenance cost
Quick installation with standardized profiles and bolted connections

Product Description

KBK crane also can be called Workstation overhead crane.Workstation overhead crane with a lifting capacity of 0.125t-2t, and a wide range of applications. The biggest advantage of our company’s Workstation overhead crane is that it can be easily expanded and adapted to new requirements at any time, and it can develop together with your business.

Technical Parameter

capacity	50 kg – 5t
span	0.7-12m
Lift height	2-8 US
Lift speed	1-22 m/min
Travel speed	3.2-40 m/min
Proletariat	A1-A6
Power supply	According to your requirements

Advantages

Good Reliability and High Stability: The KBK rail system is made with high precision. The sturdy components can ensure stable operation.
Flexible Adaptability: KBK cranes are highly customizable, allowing for flexible configurations that can adapt to different workspace layouts and lifting needs.
Easy Installation and Economical: The modular components allow for quick and straightforward assembly and installation, minimizing downtime and labor costs associated with setup.
Versatility: Suitable for a wide range of applications, including assembly lines, workshops, warehouses, and more.
